ELECTRICAL SAFETY TESTERS

SAFETY TESTER

Leading brand of safety-related test equipment

As a top brand of safety-related testing equipment that complies with the Electrical Appliance and Material Safety Law as well as safety standards around the world, many electrical and electronic equipment manufacturers in Japan and overseas have adopted our products. When introducing testing and inspection equipment related to the laws and standards of various countries, please consider the products of Kikusui Electronics Industry, which has a reliable and proven track record.

safety-related testing

TOS9300 Series

Hipot, Insulation Resistance, Ground Bond, Leakage or Partial discharge testing, this analyzer covers it all!

The TOS9300 series is a high performance electrical safety analyzer that complies to a wide range of universal standards. Hipot, Insulation Resistance, Ground Bond, Leakage Current (touch current and protective conductor current) and partial discharge can all be tested. A total of 6 models are available for standard compliance tests in a wide variety of applications including R&D, quality assurance manufacturing lines and laboratory tests.

  • AC/DC Hipot
  • Insulation Resistance
  • Ground Bond
  • Leakage Current
  • High-End Multi-type

The all-in-one multi analyzer capable of AC/DC hipot tester, insulation resistance, ground bond, and leakage current testing

  • Max. output-voltage of AC hipot testing : 5kV/100mA(500VA)
  • Max. output-voltage of DC hipot testing : 5kV/20mA, 7.2kV/13.9mA(100W)
  • Measurement range of insulation resistance testing : 0.001MΩ to 100.0GΩ(DC-25V to -1000V / DC+50V to +7200V)
  • Measurement range of ground bond testing : 0.001Ω to 0.600Ω(3.0A to 42.0A)
  • Measurement range of leakage current testing : 1µA to 100mA(rms)
  • Electrical breakdown inspection setting available
  • LAN/USB/RS232C standard digital interface
  • Easy to read LCD display for real time monitoring during tests. All measurement values and standard outlines displayed in each test

TOS9303LC Learn more

TOS9303LC
  • AC/DC Hipot
  • Insulation Resistance
  • Ground Bond
  • High-End Multi-type

AC/DC Hipot tester with insulation resistance and ground bond test capabilities

  • Max. output-voltage of AC hipot testing : 5kV/100mA(500VA)
  • Max. output-voltage of DC hipot testing : 5kV/20mA, 7.2kV/13.9mA(100W)
  • Measurement range of insulation resistance testing : 0.001MΩ to 100.0GΩ(DC-25V to -1000V/DC+50V to +7200V)
  • Measurement range of ground bond testing : 0.001Ω to 0.600Ω(3.0A to 42.0A)
  • Electrical breakdown inspection setting available
  • LAN/USB/RS232C standard digital interface
  • Easy to read LCD display for real time monitoring during tests. All measurement values and standard outlines displayed in each test

TOS9303 Learn more

TOS9303
  • AC Hipot
  • Ground Bond
  • High-End Multi-type

AC Hipot tester with ground bond test capabilities

  • Max. output-voltage of AC hipot testing : 5kV/100mA(500VA)
  • Measurement range of ground bond testing : 0.001Ω to 0.600Ω(3.0A to 42.0A)
  • New amplifier type allows for 40 A AC/DC ground bond testing
  • Electrical breakdown inspection setting available
  • LAN/USB/RS232C standard digital interface
  • Easy to read LCD display for real time monitoring during tests. All measurement values and standard outlines displayed in each test

TOS9302 Learn more

TOS9302
  • AC/DC Hipot
  • Insulation Resistance
  • Partial Discharge
  • High-End Multi-type

AC/DC Hipot tester with insulation resistance and partial discharge test capabilities

  • Max. output-voltage of AC hipot testing : 5kV/100mA(500VA)
  • Max. output-voltage of DC hipot testing : 5kV/20mA, 7.2kV/13.9mA(100W)
  • Measurement range of insulation resistance testing : 0.001MΩ to 100.0GΩ(DC-25V to -1000V/DC+50V to +7200V)
  • Insulation diagnosis available with partial discharge model
  • Electrical breakdown inspection setting available
  • LAN/USB/RS232C standard digital interface
  • Easy to read LCD display for real time monitoring during tests. All measurement values and standard outlines displayed in each test

TOS9301PD Learn more

TOS9301PD
  • AC/DC Hipot
  • Insulation Resistance
  • High-End Multi-type

AC/DC Hipot tester tester with insulation resistance capabilities

  • Max. output-voltage of AC hipot testing:5kV/100mA(500VA)
  • Max. output-voltage of DC hipot testing : 5kV/20mA, 7.2kV/13.9mA(100W)
  • Measurement range of insulation resistance testing : 0.001MΩ to 100.0GΩ(DC-25V to -1000V/DC+50V to +7200V)
  • Electrical breakdown inspection setting available
  • LAN/USB/RS232C standard digital interface
  • Easy to read LCD display for real time monitoring during tests. All measurement values and standard outlines displayed in each test

TOS9301 Learn more

TOS9301
  • AC Hipot
  • Insulation Resistance
  • High-End Multi-type

AC Hipot Tester with Insulation Resistance Test

  • Max. output-voltage of AC hipot testing : 5kV/100mA(500VA)
  • Measurement range of insulation resistance testing : 0.001MΩ to 100.0GΩ(DC-25V to -1000V)
  • Electrical breakdown inspection setting available
  • LAN/USB/RS232C standard digital interface
  • Easy to read LCD display for real time monitoring during tests. All measurement values and standard outlines displayed in each test

TOS9300 Learn more

TOS9300
  • High-voltage Scanner
  • High-End Multi-type

High-voltage scanner for TOS9300 series multi-channel testing systems

  • Output of each channel and contact with testing points can be easily monitored.
  • Up to four high voltage scanners (total 16 channels) can be connected to each unit.
  • Remote control is not limited to the TOS9300 series but is also compatible with previous models such as the TOS5300 series hipot/insulation resistance tester.

TOS9320 Learn more

TOS9320
  • DC Hipot
  • Insulation Resistance
  • High-End type

Suitable for insulation testing of PV modules

  • Max. output-voltage of DC hipot testing : 10kV/5mA
  • Measurement range of insulation resistance testing : -25V to -1500V/0.01MΩ to 9.99GΩ
  • Compatible with IEC61215, IEC61646, IEC61730-2, JIS C 8990, JIS C 8991, JIS C 8992-1&2, UL1703
  • High-precision current measurement, 1µA of the setting resolution for judgemen
  • Out of stock

TOS9213AS Learn more

TOS9213AS

TOS5300 series

New low-cost standard model that provides thorough operability, reliability and safety.

The “TOS5300 Series” is a series of test instruments used in Hipot tests and insulation resistance tests, two of the four tests regarded as necessary for ensuring the safety of electrical products. With an output of 5kV/100mA (AC) and 6kV/10mA (DC), the series can be used in Hipot & insulation resistance testing of electronic equipment and electronic parts, based on the requirements of IEC, EN, UL, VDE, JIS, and other international safety standards and the Electrical Appliance and Material Safety Law. Also, the test voltage stability is improved with the adoption of a newly developed switching amplifier. Since the output voltage can be kept constant even when the AC line voltage or frequency changes, consistent testing can be performed, even when the power supply environment is in an unstable region. The TOS5300 is also equipped with a number of features that are capable of meeting a variety of test needs. It is a new low-cost standard model that provides thorough operability, reliability and safety.

  • AC Hipot
  • Insulation Resistance

A new standard for Hipot & Insulation resistance testing Applied to World-Wide input voltage

  • The PWM amp system provides highly-stable output
  • Max. output-voltage of AC hipot testing : 5kV/100mA(500VA)
  • Measurement range of insulation resistance testing : 25V to 1000V(7 steps), 500V or greater, up to 5.00GΩ Insulation Resistance test
  • High-precision measurement ±1.5% of reading (with voltmeter 500 V or higher, Ammeter 1 mA or higher)
  • Rise/Fall time control function

TOS5302 Learn more

TOS5302
  • AC/DC Hipot

5kV / Max. output 500VA (AC), 6kV / Max. output 50W (DC) Hipot Tester

  • The PWM amp system provides highly-stable output
  • Max. output-voltage of AC hipot testing : 5kV/100mA(500VA)
  • Max. output-voltage of DC hipot testing : 6kV / Max. output 50W
  • High-precision measurement ±1.5% of reading (with voltmeter 500 V or higher, Ammeter 1 mA or higher)
  • Rise/Fall time control function

TOS5301 Learn more

TOS5301
  • AC Hipot

AC Hipot Tester with 5kV/500VA Max. output

  • The PWM amp system provides highly-stable output
  • Max. output-voltage of AC hipot testing : 5kV/100mA(500VA)
  • High-precision measurement ±1.5% of reading (with voltmeter 500 V or higher, Ammeter 1 mA or higher)
  • Rise/Fall time control function

TOS5300 Learn more

TOS5302
  • AC Hipot

A Perfect AC Hipot Test solution, with 500 VA capacity and equipped PWM amplifier at very affordable investment

  • The PWM amp system provides highly-stable output
  • Max. output-voltage of AC hipot testing : 5kV/100mA(500VA)
  • High-precision measurement ±1.5% of reading (with voltmeter 500 V or higher, Ammeter 1 mA or higher)
  • Rise/Fall time control function

TOS5200 Learn more

TOS5200
  • AC/DC Hipot

Exclusive model of TOS Series having AC, DC10 kV output

  • Complies with various safety standards
  • Equipped with remote control function
  • Various signal outputs
  • Digital voltmeter and ammeter

TOS5101 Learn more

TOS5101

Insulation Resistance Tester

Compact and convenient insulation resistance tester. Reasonable and high performance.

The TOS7200 is an insulation resistance tester available for a wide range of various electric and electronic components, as well as electric and electronic equipment. The output voltage can be set at desired value in the range of – 25V to -1,000V with a resolution of 1V. (conforms with the output characteristics of the JIS C 1302-2002) . As it is fitted with a window comparator and timer function, the tester is capable of efficiently conducting insulation resistance tests based on various safety standards. In addition, this product is equipped with panel memory as standard feature, which can be recalled by remote control, SIGNAL I/O connector, and the RS-232C interface for easy automatic testing system construction.

  • Insulation Resistance Tester

Complied with the test voltage -25 VDC to -1000 VDC of the JIS C 1302-2002

  • Measurement range of insulation resistance testing : 0.01MΩ to 5000MΩ
  • Provided with the discharge function
  • Equipped with the window comparator
  • Hold function (which holds the measured resistance at the end of testing while PASS judgment is being output)
  • Provided with the timer function

TOS7200 Learn more

TOS7200
  • PID Insulation Tester

Capable of continuous long-term operation for applying the high voltage required to the PID affect of the PV module

  • The PID insulation tester (TOS7210S) is designed based on the insulation resistance tester (TOS7200) to carry out the evaluation of the PID (Potential Induced Degradation) effect of the PV module precisely and efficiently. Being equipped with the output ability of 2000 V and the ammeter with nA resolution as well as a polarity switching function, the TOS7210S is also applicable not only to the PID evaluation but also the evaluation of the insulators that requires a high sensitivity of measurement. The tester is equipped with the panel memory that is externally accessible and RS232C interface as standard; it can be flexibly compatible with the automated system.

TOS7210S Learn more

TOS7210S

Ground Bond Tester

Ground Bond tester supporting standard compliance tests up to 60A

The TOS6210 tester extends the maximum test current from 30 A to 60 A, which is demanded by the new standard. In addition, the tester also lets you judge the acceptability of the device under test based on the drop in voltage, as required in the standard. What’s more, you can preset test conditions of up to 20 different types of safety standards, such as those for information technology equipment, home appliances, medical devices, and measuring instruments, in the memory on the main unit’s panel. A simple memory call operation allows you to set up a protective earthling or protective bonding continuity test as stipulated in UL60950-1 and other relevant specifications including IEC and JIS standards.

  • Max.60A
  • Ground Bond

Supports UL60950-1(40A / 60A) testing – New Standard for Information Technology Equipment (ITE)

  • Measurement range of ground bond testing : 0.001Ω to 0.600Ω(AC6A to 60A)
  • Capable to judge by the resistance value and the voltage drop
  • Offset cancelling function
  • Stores 100 test conditions in memory
  • Incorporates test conditions into program

TOS6210 Learn more

TOS6210
  • Max.30A
  • Ground Bond

Suitable design for the automated ground bond testing adopted with the constant current method.

  • Measurement range of ground bond testing : 0.001Ω to 1.200Ω(AC3A to 30A)
  • Capable to judge by the resistance value and the voltage drop
  • Offset cancelling function
  • Stores 100 test conditions in memory
  • Incorporates test conditions into program

TOS6200A Learn more

TOS6200A

Leakage Current Tester

Supports touch current and protective conductor current (earth leakage current) tests

The TOS3200 is designed to test for leakage current (Touch Current and Protective Conductor Current) of general electrical apparatuses, excluding those used for medical purposes. With this tester, you can conduct tests conforming to various standards including IEC, UL, JIS and Electrical Appliance and Material Safety Law (Japan). You can set test conditions through simple operations on the panel because this tester holds in its memory the 51 types of test conditions for IT-related electrical equipment, electrical appliances, audio & visual equipment, lighting fixtures, power tools, and measuring and control instruments, accordingly with the standards of IEC/JIS and Electrical Appliance and Material Safety Law.

  • Leakage Current Tester

Complying with various safety standards for general electrical equipment, this tester is used for touch current and protective conductor current tests!!

  • Measures leakage current in 3 operation modes
  • Eight types of measuring circuit networks are incorporated in the tester for measuring the touch current of general electrical apparatuses
  • Possible to measure DC/RMS/PEAK, realizing the “true root-mean-square value” with 30mA as the maximum RMS
  • User-friendly operability
  • Possible to choose between Independent and Automatic Testing
  • 51 types of preset safety standard tests
  • Function for controlling the calibration expiration limits

TOS3200 Learn more

TOS3200
