High-performance multifunctional AC Power Supplies
PCR-LE Series
PCR-LE-SERIES
550,000円 – 4,100,000円
- High-quality/high-stability output with a high-speed linear amp
- Capable of various power line abnormality simulations and sequence operation
- Single-phase 500 VA to 9 kVA, supporting the system for the single-phase, and expandable with optional drivers for the single-phase three-wire, and three-phase operation
- Expandable capacity up to 27 kVA (single-phase), 54 kVA (single-phase three-wires), and 81 kVA (three-phase)
- Equipped with various measuring functions
- Features a full range of measuring functions and supports AC, DC, and AC + DC Outputs
- Detachable front panel
- Eco-friendly function equipped
For PCR12000LE2, PCR18000LE2, and PCR27000LE2, installation costs are required separately.
| Image | SKU | 入力：皮相電力（kVA以下） | Output rating AC mode: Power capacity | 標準価格 | WEBかんたんお見積り |
|---|---|---|---|---|---|
 | PCR500LE | 0.93 | 500VA | 550,000円 （税込：605,000円） | |
 | PCR1000LE | 1.8 | 1kVA | 760,000円 （税込：836,000円） | |
 | PCR2000LE | 3.6 | 2kVA | 1,060,000円 （税込：1,166,000円） | |
 | PCR3000LE | 5.5 | 3kVA | 1,700,000円 （税込：1,870,000円） | |
| PCR4000LE | 7.3 | 4kVA | 1,990,000円 （税込：2,189,000円） | |
 | PCR6000LE | 10.6 | 6kVA | 2,900,000円 （税込：3,190,000円） | |
 | PCR9000LE | 15.7 | 9kVA | 4,100,000円 （税込：4,510,000円） |
Line-up
| Product Images | Model | Price | Output capacity | Maximum output current | AC mode (L/H range) | DC mode (L/H range) | ||
|---|---|---|---|---|---|---|---|---|
| Voltage | Maximum output current | Voltage | Maximum output current | |||||
 |
PCR500LE | 550,000円 （税込：605,000円） | Single-phase 500 VA | 5 A / 2.5 A | 1 V to 150 V / 2 V to 300 V | 5 A / 2.5 A | ±1.4 V to ±212 V / ±2.8 V to ±424 V | 3.5 A / 1.75 A |
 |
PCR1000LE | 760,000円 （税込：836,000円） | Single-phase 1 kVA | 10A / 5A | 10A / 5A | 7A / 3.5A | ||
 |
PCR2000LE | 1,060,000円 （税込：1,166,000円） | Single-phase 2 kVA | 20A / 10A | 20A / 10A | 14A / 7A | ||
 |
PCR3000LE | 1,700,000円 （税込：1,870,000円） | Single-phase 3 kVA | 30A / 15A | 30A / 15A | 21A / 10.5A | ||
|
PCR4000LE | 1,990,000円 （税込：2,189,000円） | Single-phase 4 kVA | 40A / 20A | 40A / 20A | 28A / 14A | ||
 |
PCR6000LE | 2,900,000円 （税込：3,190,000円） | Single-phase 6 kVA | 60A / 30A | 60A / 30A | 42A / 21A | ||
 |
PCR9000LE | 4,100,000円 （税込：4,510,000円） | Single-phase 9 kVA | 90A / 45A | 90A / 45A | 63A / 31.5A | ||
Specifications
Input ratings (AC rms)
| Item/Model | PCR500LE | PCR1000LE | PCR2000LE | PCR3000LE | PCR4000LE | PCR6000LE | PCR9000LE | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 3P3W 200V | 3P4W 400V | 3P3W 200V | 3P4W 400V | |||||||
| Voltage | 85 Vac to 132 Vac /170 Vac to 250 Vac *1 | 170Vac to 250Vac | Line voltage 324 V to 440 V (Phase voltage 187 V to 254 V) |
170Vac to 250Vac | Line voltage 324 V to 440 V (Phase voltage 187 V to 254 V) |
|||||
| Phase | Single phase | Single phase | Three phase 3-wire | Three phase 4-wire | Three phase 3-wire | Three phase 4-wire | ||||
| Frequency | 47 Hz to 63 Hz | |||||||||
| Apparent power | Approx. 0.93 kVA | Approx. 1.8kVA | Approx. 3.6kVA | Approx. 5.5kVA | Approx. 7.3kVA | Approx. 10.6 kVA | Approx. 15.7 kVA | |||
| Power factor *2 | 0.97 (TYP) | |||||||||
| Max. current *1 | 11.3A/5.5A | 22A/10.8A | 44A/21.5A | 66A/32A | 88A/43A | 64A | 38A | 21A | 55A | 30A |
*1 100 V input type or 200 V input type *2 When the input voltage is 100 V or 200 V, the output voltage is 100 V or 200 V, the output current is the rated value, the load power factor is 1, and the output frequency is between 40 Hz and 999.9 Hz.
AC mode output ratings (AC rms)
| Item/Model | PCR500LE | PCR1000LE | PCR2000LE | PCR3000LE | PCR4000LE | PCR6000LE | PCR9000LE | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 3P3W 200V | 3P4W 400V | 3P3W 200V | 3P4W 400V | |||||||
| Voltage (output L range, output H range) | 1 V to 150 V / 2 V to 300 V | |||||||||
| Resolution | 0.1 V | |||||||||
| Voltage setting range | 0 V to 152.5 V / 0 V to 305.0 V | |||||||||
| Voltage setting accuracy (output L range, output H range) *3 | ± (0.3 % of set + 0.6 V) | |||||||||
| Max. current*4 | 5 A/2.5 A | 10A/5A | 20A/10A | 30A/15A | 40A/20A | 60A/30A | 90A/45A | |||
| Phase | Single phase | |||||||||
| Power capacity | 500VA | 1kVA | 2kVA | 3kVA | 4kVA | 6kVA | 9kVA | |||
| Maximum peak current *5 | Max. current (rms) × 4 (TYP) | |||||||||
| Max. reverse current *6 | 30 % of the max. current (rms) | |||||||||
| Load power factor | 0 to 1 (leading or lagging) *4 | |||||||||
| Frequency *4 | 1 Hz to 999.9 Hz | |||||||||
| Resolution | 0.01 Hz (1.00 Hz to 100.0 Hz), 0.1 Hz (100.0 Hz to 999.9 Hz) | |||||||||
*3 When the output frequency is between 45 Hz and 65 Hz, with no load, and at room temperature. *4 When the maximum voltage is between 1 V and 100 V (L range) or 2 V and 200 V (H range) and the load power factor is between 0.8 and 1. When the output voltage is between 100 V and 150 V (L range) or 200 V and 300 V (H range), the output current is reduced by the output voltage. When the load power factor is between 0 and 0.8, the output current is reduced by the load power factor. When the output frequency is between 1 Hz and 40 Hz, the output current is reduced by the output frequency. *5 For capacitor-input rectifier loads (however, this is limited by the rated output current’s rms value). *6 When the output voltage is 100 V or 200 V and the output frequency is between 40 Hz and 999.9 Hz (reverse current is -180 deg out of phase with the output voltage).
DC mode output ratings
| Item/Model | PCR500LE | PCR1000LE | PCR2000LE | PCR3000LE | PCR4000LE | PCR6000LE | PCR9000LE | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 3P3W 200V | 3P4W 400V | 3P3W 200V | 3P4W 400V | |||||||
| Voltage (output L range, output H range) | ±1.4 V to ±212 V / ±2.8 V to ±424 V | |||||||||
| Resolution | 0.1 V | |||||||||
| Voltage setting range | -215.0 V to +215.5 V / -431.0 V to +431.0 V | |||||||||
| Voltage setting accuracy (output L range, output H range) *7 | ±(0.05 % of set + 0.05/0.1 V) | |||||||||
| Max. current *8 | 3.5A/1.75A | 7A/3.5A | 14A/7A | 21A/10.5A | 28A/14A | 42A/21A | 63A/31.5A | |||
| Max. instantaneous current *9 | Max. current (rms) × 3.6 | |||||||||
| Power capacity | 350W | 700W | 1.4kW | 2.1kW | 2.8kW | 4.2kW | 6.3kW | |||
*7 With no load at room temperature *8 When the output voltage is between ±100 V and ±212 V (L range) or ±200 V and ±424 V (H range), the output current is reduced by the output voltage. *9 Limited by the rated output current’s rms value
Output voltage stability
| Item/Model | PCR500LE | PCR1000LE | PCR2000LE | PCR3000LE | PCR4000LE | PCR6000LE | PCR9000LE | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 3P3W 200V | 3P4W 400V | 3P3W 200V | 3P4W 400V | |||||||
| Line regulation *10 | Within ±0.1 % | |||||||||
| Load regulation (output L range, output H range) *11 | Within ±0.1 V, within ±0.2 V | |||||||||
| Output frequency FAST variation *12 | FAST | ±0.2 % or less | – | |||||||
| MEDIUM | Within ±0.3 % | |||||||||
| Ripple noise in DC mode (5 Hz to 1 MHz components) | 0.15 Vrms or less | 0.2 Vrms or less | 0.25 Vrms or less | |||||||
| Ambient temperature variation *13 | 100 ppm/°C (TYP) | |||||||||
*10 With respect to changes in the rated range *11 With respect to 0 % to 100 % changes in the rating When the output voltage is between 80 V and 150 V (L range) or 160 V and 300 V (H range) and the load power factor is 1. At the output terminal block. When the response mode is set to FAST or MEDIUM. *12 Between 40 Hz and 999.9 Hz. When the output voltage is between 80 V and 150 V (L range) or 160 V and 300 V (H range) and the load power factor is 1. This is the output line regulation with 200 Hz as the reference. *13 With respect to changes in the rated range When the output voltage range is 100 V or 200 V and the output current is 0 A.
Output frequency stability, output voltage waveform distortion ratio, output voltage response speed, efficiency
| Item/Model | PCR500LE | PCR1000LE | PCR2000LE | PCR3000LE | PCR4000LE | PCR6000LE | PCR9000LE | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 3P3W 200V | 3P4W 400V | 3P3W 200V | 3P4W 400V | |||||||
| Output frequency stability *14 | Within ±5×10– 5 | |||||||||
| Setting accuracy *2 | Within ±1×10– 4 | |||||||||
| Output voltage waveform distortion ratio*15 | FAST | ±0.2 % or less | – | |||||||
| MEDIUM | ±0.3 % or less | |||||||||
| Output voltage response speed*16 | FAST | 20 μs (TYP) | – | |||||||
| MEDIUM | 30 μs (TYP) | |||||||||
| Efficiency *17 | 54 % or more, 56 % or more | 55 % or more, 57 % or more | 58 % or more | |||||||
*14 With respect to changes in all rated ranges *15 When the output voltage is between 80 V and 150 V (L range) or 160 V and 300 V (H range) and the load power factor is 1. *16 When the output voltage is 100 V or 200 V, the load power factor is 1, and the output current changes from 0 A to the rated value and from the rated value to 0 A. *17 When the input voltage is 100 V or 200 V, the output voltage is 100 V or 200 V, the output current is the rated value, the load power factor is 1, and the output frequency is between 40 Hz and 999.9 Hz.
Meters (fluorescent display)
| Item/Model | PCR500LE | PCR1000LE | PCR2000LE | PCR3000LE | PCR4000LE | PCR6000LE | PCR9000LE | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 3P3W 200V | 3P4W 400V | 3P3W 200V | 3P4W 400V | |||||||
| Voltmeter *18 | Resolution | 0.1 V | ||||||||
| Accuracy | ± (1 % of rdng + 2 digits) (10 V to 424 V and at room temperature) | |||||||||
| Ammeter *18 | Resolution | 0.01 A | 0.1 A | |||||||
| Accuracy | ±(1 % of rdng + 2 digits) (5 % of the max. rated current to max. rated current and at room temperature) | |||||||||
| Wattmeter *19 | Resolution | 0.1 W / 1W | 1 W | |||||||
| Accuracy | ±(1 % of rdng +3 digits) (10 % of the rated power capacity to the rated power capacity, when the load power factor is 1, and at room temperature.) | |||||||||
*18 With the true rms display, a waveform with a crest factor of 3 or less, DC, output frequency between 40 Hz and 999.9 Hz, RMS, and AVE. *19 When the output frequency is between 45 Hz and 65 Hz.
BNC terminals
| Item/Model | PCR500LE | PCR1000LE | PCR2000LE | PCR3000LE | PCR4000LE | PCR6000LE | PCR9000LE | ||
|---|---|---|---|---|---|---|---|---|---|
| 3P3W 200V | 3P4W 400V | 3P3W 200V | 3P4W 400V | ||||||
| SEQ TRIG OUT *20 | Pulse width approx. 10 μs, open collector output, pullup at +5 V and approx. 10 kΩ serial resistance approx. 220 Ω, maximum sink current 10 mA, BNC connector | ||||||||
| SEQ STAT OUT *20 | Step time output, open collector output, pullup at +5 V and approx. 10 kΩ serial resistance approx. 220 Ω, maximum sink current 10 mA, BNC connector | ||||||||
| SEQ TRIG IN *20 | Operating pulse width 10 μs or greater, photo-coupler input, driving voltage 5 V, serial resistance approx. 470 Ω, active with 7 mA source, BNC connector | ||||||||
*20 Although signals are insulated with output terminals, each signal is common. Logic setting is also possible.
Limit Values and Protection Functions
| Item/Model | PCR500LE | PCR1000LE | PCR2000LE | PCR3000LE | PCR4000LE | PCR6000LE | PCR9000LE | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 3P3W 200V | 3P4W 400V | 3P3W 200V | 3P4W 400V | |||||||
| Voltage | AC voltage upper limit / AC voltage lower limit | 0.0 V to 305.0 V | ||||||||
| DC voltage upper limit / DC voltage lower limit | -431.0 V to +431.0 V | |||||||||
| Output overvoltage protection AC/AC+DC mode | 0.0 V to 474.1 V | |||||||||
| Output overvoltage protection DC mode | -474.1 V to +474.1 V | |||||||||
| Output undervoltage protection AC/AC+DC mode | 0.0 V to 474.1 V | |||||||||
| Output undervoltage protection DC mode | -474.1 V to +474.1 V | |||||||||
| Resolution | 0.1 V | |||||||||
| Frequency | Upper limit / Lowerlimit | 1 Hz to 999.9 Hz *1 | ||||||||
| Resolution | 0.01 Hz (1.00 Hz to 100.0 Hz), 0.1 Hz (100.0 Hz to 999.9 Hz) | |||||||||
| Current | Current limit*2 AC mode | 0.50A to 5.50A | 1.00A to 11.00A | 2.00A to 22.00A | 3.00A to 33.00A | 4.00A to 44.00A | 6.00A to 66.00A | 9.00A to 99.00A | ||
| Current limit*2 DC/AC+DC mode | 0.35A to 3.85A | 0.70A to 7.70A | 1.40A to 15.40A | 2.10A to 23.10A | 2.80A to 30.80A | 4.20A to 46.20A | 6.30A to 69.30A | |||
| Positive peak current limit*3 | 0.50A to 22.00A | 1.00A to 44.00A | 2.00A to 88.00A | 3.00A to 132.0A | 4.00A to 176.0A | 6.00A to 264.0A | 9.00A to 396.0A | |||
| Negative peak current limit*3 | -0.50A to -22.00A | -1.00A to -44.00A | -2.00A to -88.00A | -3.00A to -132.0A | -4.00A to -176.0A | -6.00A to -264.0A | -9.00A to -396.0A | |||
| Resolution *4 | 0.01 A (0.35 A to 100.0 A), 0.1 A (100.0 A to 396.0 A) | |||||||||
*1 The frequency is limited to the range from 1 Hz to 500.0 Hz when the 3P05-PCR-LE(500HZ LMT) is installed in the PCR-LE series. *2 The current that can actually be supplied is 1.1 times the rated current or the current limit, whichever is less.*3 The current that can actually be supplied is the maximum peak current or the current limit, whichever is less.*4 You can set the current in 0.01 A/ 0.1 A steps, but it may not change at this resolution depending on the relationship with the internal D/A resolution.
General
| Item/Model | PCR500LE | PCR1000LE | PCR2000LE | PCR3000LE | PCR4000LE | PCR6000LE | PCR9000LE | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 3P3W 200V | 3P4W 400V | 3P3W 200V | 3P4W 400V | ||||||||
| Insulation resistance | Between input and chassis, output and chassis, and input and output | 500 Vdc, 30 MΩ or more | 500 Vdc, 10 MΩ or more | ||||||||
| Withstanding voltage | Between input and chassis, output and chassis, and input and output | 1.5 kVac for 1 minute | |||||||||
| Circuit method | Linear amplifier system | ||||||||||
| Environmental conditions | Operating environment | Indoor use, overvoltage category II | |||||||||
| Operating temperature range | 0 °C to +50 °C (32 °F to +122 °F) | ||||||||||
| Storage temperature range | -10 °C to +60 °C (14 °F to 140 °F) | ||||||||||
| Operating humidity range | 20 %rh to 80 %rh (no condensation) | ||||||||||
| Storage humidity range | 90 %rh or less (no condensation) | ||||||||||
| Altitude | Up to 2000 m | ||||||||||
| Weight | Approx. 17 kg (37.48 lb) | Approx. 35 kg (77.16 lb) | Approx. 55 kg (121.25 lb) | Approx. 82 kg (180.78 lb) | Approx. 96 kg (211.64 lb) | Approx.140 kg (308.6 Ibs) | Approx.190kg (418.8 Ibs) | ||||
| Input terminal | (Inlet) | M4 | M5 | M8 | M8 | M8 | M5 | M5 | M5 | M5 | |
| Output terminal | M4 | M4 | M4 | M5 | M5 | M8 | M8 | M8 | M8 | M8 | |
| Accessories | Power cord | 1 pc. With plug, Length: 3 m | The input power cable is not included. Please refer to the list of ordering information specified on the last page. | ||||||||
| Heavy Duty Warning Seals | − | 1 disc | |||||||||
| Setup guide | 1 copy | ||||||||||
| Quick Reference | 1 each for English and Japanese | ||||||||||
| Safety information | 1 copy | ||||||||||
| CD-ROM | 1 disc | ||||||||||
| Electromagnetic compatibility (EMC) *5 *6 | Conforms to the requirements of the directive and standard below. EMC Directive 2014/30/EU EN61326-1(ClassA *7), EN55011(ClassA *7, Group1 *8) EN61000-3-2, EN61000-3-3 The maximum length of all cables and wires connected to the PCR-LE Series must be less than 3 m. | Conforms to the requirements of the directive and standard below. EMC Directive 2014/30/EU EN61326-1(ClassA *7), EN55011(ClassA *7, Group1 *8) The maximum length of all cables and wires connected to the PCR-LE Series must be less than 3 m. | |||||||||
| Safety *5 | Conforms to the requirements of the directive and standard below. Low Voltage Directive 2014/35/EU *6 EN 61010-1 Class I *9, Pollution Degree 2 | ||||||||||
*5 Does not apply to specially ordered or modified PCR-LEs. *6 Only on models that have the CE marking on the panel. *7 This is a Class A equipment. This product is intended for use in an industrial environment. This product may cause interference if used in residential areas. Such use must be avoided unless the user takes special measures to reduce electromagnetic emissions to prevent interference to the reception of radio and television broadcasts.*8 This is a Group 1 equipment. This product does not generate and/or use intentionally radio-frequency energy, in the form of electromagnetic radiation, inductive and/or capacitive coupling, for the treatment of material or inspection/analysis purpose. *9 This is a Class I equipment. Be sure to ground this product’s protective conductor terminal. The safety of this product is only guaranteed when the product is properly grounded.
Options
Input power cord/Power-sync cable
For PCR1000LE
For PCR2000LE
For PCR3000LE
For PCR4000LE
For PCR6000LE (single-phase, 2-wire)
For PCR6000LE (three-phase, three-wire)
For PCR9000LE (three-phase, three-wire)
For PCR6000LE / PCR9000LE (3-phase 4-wire)
Drivers
(for master unit operated in parallel)※1 ※2
(for slave unit operated in parallel)※1 ※2
Three-phase output driver / Three-phase output driver(500 Hz LMT)
For single-phase 3-wire output
Rack Mount Bracket
For PCR500LE
For PCR1000LE
For PCR2000LE
Connecting cable (for 2P05,3P05)
Power signal cable
Connecting cable
Power Signal Cable
Interface
For GPIB
for USB
For LAN/LXI
Analog signal interface boards※3 ※4 ※5 ※6
IEC Dip·Simulator
Line Impedance Network
Extension cable for control panel
Base Hold Angles
1 PCR500LE and PCR1000LE cannot be used. 2 Up to 5 units can be used in parallel. (Power within 27kVA) *3 Input waveforms are amplified and output as they are. 4 Multi-output models (6000LE2, 9000LE2) cannot amplify input waveforms in multi-phase output mode. 5 The output AC voltage value can be varied according to the input DC signal. 6 The multi-output models (6000LE2, 9000LE2) cannot control the amplitude in the multi-phase output mode.
Software
More convenient and easy to use! Appliquation software to help you with your exams
